DPV PP VERTICAL SUMP PUMP
The DPV PP Vertical Sump Pump is a high-performance, non-metallic vertical pump engineered for efficient and reliable handling of corrosive and acidic fluids. Designed with robust polypropylene (PP) construction, it is ideal for sump applications in aggressive chemical environments where conventional pumps fail due to corrosion or leakage.
Operating Data
| Capacity | Up to 80 M³/hr |
|---|---|
| Head | Up to 60 Mtr. |
| Pump Length | 3 meter |
| Temperature | Up to 200°C |
| Speed | Up to 3500 rpm |
| Pressure | Up to 6 Kg/Cm² |
| M.O.C. | CI, CS, SS304, SS304L, SS316, SS316L, Alloy-20, CD4MCuN, etc. |
Applications:
- Handling clear water and slurry liquids
- Chemical Industry
- Petrochemical Processing
- Pharmaceutical Industry
- MEE Plants
- Condensate Transfer
- Acid Transfer
- Sludge Transfer
Key Features:
- Sealless vertical design eliminates leakage
- Suitable for highly corrosive and acidic fluids
- PP construction offers excellent chemical resistance
- Capable of handling clear as well as slurry liquids
- Pump length up to 3 meters
- Handles temperatures up to 200°C
- Available in multiple M.O.C. options like PP, SS304, SS316, Alloy-20 etc.
- Easy to maintain and install
- Energy-efficient performance with up to 3500 rpm
Optional Accessories:
- Baseplate and coupling
- Control panel and electrical wiring
- Vibration dampeners
- Pressure gauge and flow meter
- Suction and discharge fittings
